Application:

The 600/1000V aluminum concentric cable is commonly used for service entrance to power transmission.

Standard:

ASTM-B; ASTM-D; UL

Construction:

1. Conductor: 8000 Series aluminum alloy

2. Insulation: XLPE

3. Cable Inner Sheath: PVC

4. Concentric Conductor Layer: 8000 Series aluminum alloy

5. Cable Tape: Non-absorbent material or OEM

6. Cable Outer Sheath: XLPE/PVC/PE

Advantages:

1. Factory direct sale

2. Abundant experiences, good quality, and cheap price

3. Free sample

Why Choose ZMS Cable?

ZMS Cable Group has a wide product scope, including Power cables up to 500kV, AAC, AAAC, ACSR conductors, ABC overhead cable, electric wires, control cable, instrument cable, telecommunications cable, and Stay wires.

With advanced manufacturing technology, rich human resource, and an effective management system, we guarantee all products are manufactured strictly by GB, IEC, BS, NFC, ASTM, DIN standards, etc.

Beyond quality control, ZMS has been trying its best to offer a much higher standard of services rather than expected.

Technical Data:

8000 Series Aluminum Alloy Conductor
Cable Type	Conductor	Insulation Thickness	Concentric Conductor	Outer Sheath Thickness	O.D of the cable
AWG	mm	mm	mm	mm	mm
2X8 AWG	7/1.23	1.14	65/0.405	1.14	11.3x17.3
2X6 AWG	7/1.55	1.14	65/0.511	1.14	13.2x20.0
2X4 AWG	7/1.96	1.14	65/0.643	1.52	14.7x22.9
2X2 AWG	7/2.47	1.14	65/0.823	1.52	16.6x26.3

Concentric Cable
