Identifications of designation
H Harmonized standard
An Authorised national standard
Nominal voltage
01 100/100V
03 300/300V
05 300/500V
07 450/750V
1 0,6/1kV
Insulating material
V Polyvinyl chloride (PVC)
V2 Heat-resistant PVC (until +90°C)
V3 Low-temperature PVC
B Ethylene-propylene-rubber (EPR)
E Polyethylene (PE)
X XLPE
R Synthetic
S Silicone rubber (SiR)
Sheath material
V PVC
V2 Heat-resistant PVC (until +90°C)
V3 Low-temperature PVC
V5 Reinforced oil resistant PVC
Q PUR (Polyurethan)
J Glass-fiber braiding
R Natural and synthetic rubber
N Chloroprene rubber (CR)
S Silicon rubber
T Textile braiding
Special structural features
C Copper braiding
H Flat, divisible cable (twin cable)
H2 Flat, non-divisible cable (two-core sheathed cable)
H6 Flat, non-divisible cable (multi-core sheathed cable)
H8 Spiral cables
Conductor type
U Single-wire, round section, class 1
R Multi-wire, round section, class 2
K Fine-wired in cables for fixed installation
F Fine-wired in flexible cables
H Ultra fine-wired in flexible cables
D Fine-wired, for welding cables
E Ultra is fine-wired, for welding cables
Z Conductor with special material
Number of cores
Protective conductor
J With protective conductor (with gr/ye)
O Without protective conductor (without gr/ye)
Nominal conductor cross-section in mm2
